CWT5110 Flow Meter Pulse Counter GPRS Data Logger, GPRS Pulse Data Logger

  • CWT5110 Flow Meter Pulse Counter GPRS Data Logger, GPRS Pulse Data Logger
  • CWT5110 Flow Meter Pulse Counter GPRS Data Logger, GPRS Pulse Data Logger
Model No.︰CWT5110
Brand Name︰CWT
Country of Origin︰China
Unit Price︰US $ 135 / pc
Minimum Order︰1 pc
Share on:

 Total 17 Related Items
Prev1011121314Next

Product Description

  CWT5110 Flow Meter Pulse Counter GPRS Data Logger, GPRS Pulse Data Logger

                                        Supports 3G version   Skype: glare.wang



1- CWT5110 is capable of logging a fast pulse counter output from flow meters, then logging to local GPRS software. Users can view real-time data, or store to a file folder.



2- It has 4 pulse inputs, the min speed is 100ms per counter



QQ20141231105702



Advance features

  • Specifically designed for remote Hydrological Data Acquisition System base on GPRS
  • Adopted highly integrated industrial CPU
  • 16Mbits flash maintaining max.30 days period of data
  • Reliable performance with built-in double watchdog
  • Low maintenance, 24×7 operation
  • Audio in and audio out can connect speak and mic
  • Temperature sensor (optional)
  • Internal battery and providing power cut off alarm
  • Easy-configured graphic interface application software

Vending Machine Monitoring System.JPG

How to setup

  • Can be setup by free PC software via serial port
  • Can be setup by phone number via sms commands

Where does GPRS RTU upload data to

  • Support connects 4 servers, the servers must connect internet and have static public IP address or Dynamic Domain name
  • GPRS Transmission base on TCP/IP
  • Support modbus TCP protocol or CWT_IO protocol

When does GPRS RTU upload data

  • GPRS RTU start up
  • Water level above preset change value
  • Rainfall value upload on schedule
  • Digital inputs are triggered
  • AD input above preset rang
  • The change of AD input above preset value
  • DI and AD data upload on schedule(day/minute/second)
  • Query by server

SMS features

  • Preset 10 phone numbers(can be distributed authority)
  • Time stamped in alarm or recover messages
  • Support remote setting and control via sms commands'

Screentshot of program software- Set pulse counter parameters:



CWT5110 COunter.jpg



Screentshot of program software- Set Upload pulse counter parameters:



CWT5110 counter01.jpg





Screensht of Program Softare-Set GPRS Paremeters:



GPRS Set up.jpg



  Screensht of Program Softare-Set View Pulse Counter data on GPRS software:



GPRS Server.jpg



Payment Terms︰T/T Western Union Paypal
